8MR2401UA

Series number 8MA-8MH-8MR

Self Excite

Fix circle (Mount): 82.3mm Fix circle (Adjuster): 83.31mm Bracket angle: -30° / 0° / 30°

Cut in speed: 1700, Max speed: 8000

Weight: 5.47kg

System voltage 12 Output 105A

Mounting style SPOOL

Dimensions in INCHES Spool length 1

Rotation BI-DIRECTIONAL

Housing coating E-COAT

UL Approved Yes

Mounting bolt size .505-.520 Mounting ear size 5/16-18 NC (3 HOLE) Mounting holes 3

Positive stud 1/4-20 NC Negative stud 1/4-20 NC

Rectifier location INTERNAL Shaft diameter .6265-.6272

Excitation type Self Excite Regulator location

Integral Regulator number 8RG2043

Adjustable regulator Yes
